SICK CLV 45 Series User Manual

Operating Instructions Chapter 4
CLV 45x Bar Code Scanner
Installation
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
4-1
4
Installation
4.1 Overview of the installation steps
•
Replacing the language version of the laser warning label (if required)
•
Selecting the installation site for the CLV
•
Aligning the CLV to the bar code
•
Installing the CLV
•
Installing the AMV/S 40 connection module
•
Connecting the CLV to the AMV/S 40 connection module
•
Adjusting the CLV
•
Installing the reading-pulse sensor for reading pulse triggering
•
Optional for focal point changeover:
Mounting the sensor for detecting the object distance
4.2 Preparations for installation
4.2.1 Laying out the components to be installed ready
•
CLV bar code scanner
4.2.2 Laying out the accessories ready
•
Mounting bracket No. 2 020 410 with two screws M 5 x 8 mm and 2 washers (not
included in the CLV scope of delivery ) or
Mounting bracket No. 2 022 564 with 3 screws M 5 x 8 mm, 3 spring washers and 2
hexagon screws M 5 x 12 mm with washers (not included in the scope of delivery) or
Rod clamp No. 2 023 691 with 3 screws M 5 x 8 mm and 3 spring washers (not inclu-
ded in the scope of delivery)
Alternatively, if the user provides a retainer:
Stable mounting device which allows the alignment of the CLV to be changed in the
X- and Y-axes. In the line scanner version the weight of the CLV amounts to 530 g, while
the line scanner with oscillating mirror weighs 700 g, each with a connection cable.
Two screws M 5 for the CLV. The screw length depends on the wall thickness of the
retainer used. Max. screw-in depth into CLV 5 mm from housing surface.
•
AMV/S 40 connection module, optionally additionally with CL 20 mA interface conver-
ter (not included in the CLV scope of delivery)
•
Reading-pulse sensor for external reading-pulse triggering, e. g. photoelectric reflex
switch/photoelectric proximity switch (not included in the CLV scope of delivery)
•
Optional for focal point changeover: Sensor for detecting the reading distance, e. g.
photoelectric reflex switch/photoelectric proximity switch (not included in the CLV
scope of delivery)
4.2.3 Laying out the required tools ready
•
Two/three screws M 5 for fastening the SICK mounting bracket to the mounting base.
Screw length depends on the wall thickness of the base.
•
Set of laser warning labels (if required)
