SICK CLV 45 Series User Manual

Operating Instructions Chapter 1
CLV 45x Bar Code Scanner
Notes on this document
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
1-1
1
Notes on this document
1.1 Function
This document instructs you on using the bar code scanner
•
CLV 450 with dynamic focal position adjustment
•
CLV 451 with dynamic focal position adjustment, optimized on 0.5 mm module width
in the variants
•
Line scanner
•
Line scanner with oscillating mirror
The document contains information on
•
Device installation and electrical installation
•
Startup
•
Operation and configuration (parameterization)
•
Maintenance
•
Device replacement with importing of the parameter record
•
Special applications and processes
The bar code scanners will all simply be called "CLV" below, except in such text passages
where a differentiation is required.
1.2 Target audience
Target audience for this document are persons with the following activities:
1.2.1 Installation, electrical installation, maintenance, device replacement
Electricians and service technicians
1.2.2 Startup, operation and configuration
Technicians and engineers
1.3 Information content
This document contains all the information required for the installation, electrical installation
and startup of the CLV with the default setting in our works.
All actions are described step-by-step.
The configuration of the CLV for the application-specific read situation is carried out with
the Windows-oriented "CLV-Setup" PC software and the "CLV Assistant". The "CLV-Setup
Help" online help system is available as an additional help. Installation of the software and
use of the user interface are described in the appendix.
Further information on the construction of the bar code scanner as well as the bar code
technology can be obtained from SICK AG, Auto Ident Division.
