Operating Instructions Chapter 10
CLV 45x Bar Code Scanner
Appendix
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
10-19
10.3 System messages
The CLV outputs all system messages in plain text on the terminal interface only. The mes-
sages are in English and can be displayed in the extended terminal emulator mode in the
CLV-Setup user interface.
(Refer to
Chapter 6.6.1 Displaying messages, Page 6-30).
Message Meaning
"
CLV 45x
Soft.Vers. VX.XX
Rev. No. 0000
Host: RS232
"
Information on the software version and revision is displayed when
the supply voltage is switched on.
"
no code
" In Reading/Parameter evaluation mode, the CLV indicates that no
codes matching the parameterized evaluation conditions were
detected during the read port
(error status ST = 2 output on the host interface).
"
laser safety timeout
" The CLV has deactivated the laser diode 10 min. (default setting)
after the start of a reading pulse. The reading interval is still active,
even though the CLV is no longer reading. The reading interval has to
be terminated by a corresponding pulse signal.
The laser diode is activated again with the next reading pulse.
"cancel Auto Setup"
The CLV has terminated the Auto Setup, without a valid bar code
being found in the search run.
Table 10-4: CLV system messages
