SICK CLV 45 Series User Manual

Chapter 10 Operating Instructions
CLV 45x Bar Code Scanner
10-52
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Appendix
10.11.3 Bus connection modules
10.11.4 Cables and connectors
Order no. Type Description
6 020 896 BMV 10-0111
Bus connection module for connection of max. two CLVs to
Profibus DP
; for the CLV 45x each
with a 15-pin D Sub HD device socket. With a 9-pin D Sub bus socket, terminal strips (signal
distributors) for wiring the RS 232 data interface and the functional interfaces, two internal 9-pin D
Sub "Service" plugs, cable grips, die-cast aluminum housing, enclosure rating max. IP 54 (enclosure
rating max. IP 65 with a plug hood), operating voltage 20 to 30 V DC
6 020 893 BMH 10-0111
Bus module for connection of a CLV to
Profibus DP
; with terminal screws, a 9-pin D-sub bus
socket, no housing, for top-hat-rail installation, enclosure rating max. IP 20, operating voltage
10 to 30 V DC
6 021 190 BMV 10-0311
Bus connection module for connection of max. two CLVs to
DeviceNet,
terminal strips for bus
connection, otherwise, as BMV 10-0111
6 021 188 BMH 10-0311
Bus module for connection of one CLV to
DeviceNet
, otherwise as BMH 10-0111
1 012 672 BMS 10-0113
Bus connection module for the connection of one CLV to
Interbus-S
; for the CLV 45x with a
15-pin D Sub HD device socket, two 9-pin D Sub bus connections (in/out), terminal strips (signal
distributors) for wiring the data and functional interfaces, internal 9-pin D Sub "Service" plug,
integrated power supply 230 V AC 50 Hz/ 24 V DC, cable grips, polycarbonate housing, enclosure
rating max. IP 54
1 012 680 BMS 10-0112 as BMS 10-0113, but with integrated 115 V AC 50/60 Hz/24 V DC power supply
6 025 757 BMV 10-0411
Bus connection module for the connection of max. two CLVs to
Ethernet
.
TCP/IP communication, data transmission rate 10 MBit/s.
For each CLV 42x with a 15-pin D Sub HD device socket. With a 8-pin RJ-45 bus socket, terminal
strips (signal distributors) for wiring the RS 232 data interface and the functional interfaces, two
internal 9-pin D Sub "Service" plugs, cable grips, die-cast aluminum housing, enclosure rating max.
IP 54 (enclosure rating max. IP 65 with a plug hood), operating voltage 20 to 30 V DC
6 025 756 BMH 10-0411
Bus module for connection of one CLV to
Ethernet.
TCP/IP communication, data transmission rate 10 MBit/s.
With terminal screws, a 8-pin RJ-45 bus socket, no housing, for top-hat-rail installation, enclosure
rating max. IP 20, operating voltage 10 to 30 V DC
6 022 140 BMV 10-0431 as BMV 10-0411, but with FTP communication, data transmission rate 10/100 MBit/s
6 025 748 BMH 10-0431 as BMH 10-0411, but with FTP communication, data transmission rate 10/100 MBit/s
6 007 655 – Power cable, 3-wire, length 2 m, with 3-pin connector (grounding) and one open end (stripped)
Table 10-12: Accessories: Bus Connection modules
Order No. Description Cores Length Connection
6 010 075 Extension cable for data and function interfaces,
∅
6.5 mm,
shielded, with 15-pin D-Sub HD socket and plug
15 2 m CLV 45x to
AMV/S 40
6 010 137 Connection cable for data and function interfaces,
∅
6.5 mm, with
15-pin D-Sub HD socket and one open end (stripped)
15 2 m CLV 45x to non-
SICK supply
system device
2 014 054 RS-232 data connection cable,
∅
5 mm, shielded, with two 9-pin
D-Sub sockets (Pin 2 (RxD) and Pin 3 (TxD) transposed)
3 3 m PC to AMV/S 40
6 010 088 Data cable,
∅
6.6 mm, shielded, for connections up to 3 m in length 15 x
0.09 mm
2
Bought
to size
Free wiring
6 007 508 Data cable,
∅
8.5 mm, twisted pair, shielded 2 x 2 x
0.23 mm
2
Bought
to size
SICK network
(RS-485)
6 009 438 D-Sub connector housing (metal) for 9-pin or 15-pin HD inserts
6 007 335 D-Sub connector insert, 9-pin female multi-point connector (socket)
Table 10-13: Available accessories: Cables and connectors
