Operating Instructions Chapter 9
CLV 45x Bar Code Scanner
Technical data
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
9-3
9.3 Dimensional drawings CLV
9.3.1 Line scanner
Fig. 9-1: Dimensions of the line scanner
60
35.9
90
50°
59.5
35.9
10
4
35.7
13.2
14.4
10
4
CLV 450-0010
CLV 451-0010
Blind hole thread,
M 5, 5 mm deep
Blind hole thread,
M 5, 5 mm deep
All specifications in mm
