Chapter 3 Operating Instructions
CLV 45x Bar Code Scanner
3-4
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Product description
3.1.5 Design line scanner with oscillating mirror
Fig. 3-2: Design of the line scanner with oscillating mirror CLV 45x
Side-end reading window
1
6
4
3
2
2
5
7
8
Legend:
1
D-Sub HD cable plug, 15-pin
2
Blind hole thread, M 5, 5 mm deep
3
Laser warning lables
4
Connection cable
5
Sound opening of the beepers (concealed)
6
LEDs (status indicators)
7
Integrated oscillating mirror
8
Reading window
