9.1 Data sheet CLV 45x line scanner
Type CLV 450-0010 CLV 451-0010
Reading window On front
Laser diode (wavelength) Red light (
λ
=650nm)
Operating life of the laser diode MTBF 20 000 h
Laser class of the device
Class 2 (to DIN EN 60825-1), de-activation of the laser diode after 10 min
1)
Effective aperature angle Max. 50
°
Scan/decoding frequency 400 ... 1000 Hz
Resolution 0.25 ... 1.0 mm 0.5 ... 1.0 mm
Focus control Dynamic focal position changeover
Number of distance configurations
(DC)
2
Max. 8
Focus adjustment time
≤
50 ms (from minimum to maximum focal position)
Focus triggering source Switching input "Sensor 2"/Serial interface/Timer
Reading ranges Refer to the reading area diagrams Chapter 10 Appendix, Page 10-1
Bar code printing contrast (PCS)
≥
60 %
Ambient light compatibility 2000 lx (on bar code)
Number of bar codes per scan 1 ... 20 (standard decoder), 1 ... 6 (SMART decoder)
Number of bar codes per read port
3)
1 ... 50 (auto-discriminating)
Bar code types (SMART decoder)
4)
Code 39, Code 128, Code 93, Codabar, EAN, EAN 128, UPC, 2/5 Interleaved
Bar code length
Max. 50 characters
5)
(max. 500 characters across all bar codes per reading interval)
Printing ratio 2:1 ... 3:1
Number of multiple readings 1 ... 99
Optical displays 4 x LEDs (status indicators)
Acoustic display Beeper, interruptible, can have function for result status display assigned
Reading pulsing Switching input "Sensor 1"/ free running/serial interface
Data interface "Host" RS-232 or RS-422/485, data output format can be set
Data transmission rate 300 ... 57 600 bits/s
Protocols SICK standard, SICK network and 3964(R)
Physical configurations Stand-alone, SICK network (bus), daisy chain (pass-through or master/slave)
Data interface "CAN" 10 kbits/s ... 1 Mbits/s
Data interface "Terminal" RS-232, 9 600 bits/s, 8 data bits, no parity, 1 stop bit, fixed output format
Function switching inputs 2 ("Sensor 1", "Sensor 2")
– Opto-decoupled, V
Imax
= 28 V, non-interchangeable, can be wired to PNP outputs
– "Sensor 1" (reading pulse): Internal delay time max. 30 ms/reduced max 0.6 ms
– "Sensor 2" (function selectable): Internal delay time max. 30 ms
Function switching outputs 2 ("Result 1", "Result 2")
–PNP, I
omax
= 100 mA, short-circuit-proof, adjustable pulse duration (stat.,
10 ... 990 ms)
– Output function of the result status selectable
Electrical connection 15-pin D-Sub HD plug, cable length 0.9 m
Operating voltage/power consumption 10 ... 30 V DC/6 W
Housing Zinc diecast, no source of faults for coating wetting
Table 9-1: Technical specifications line scanner
