10.17 Bar code sample
Fig. 10-35: Scannable bar codes of various module widths (printing ratio 2:1)
9876543210
A1234A
CLV450
4 096072 616559
2/5 interleaved
EAN 13-digit
Code 39
Codabar
Module width
0.25 mm
Module width
0.35 mm
Module width
0.5 mm
Module width
1.0 mm
!§$
"
