Chapter 3 Operating Instructions
CLV 45x Bar Code Scanner
3-2
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Product description
– or –
Alternatively a non-SICK supply system device with an output voltage of 10 ... 30 V DC
in accordance with IEC 742 (functional extra-low voltage) and at least 10 W power out-
put. The connection cable No. 6 010 137 with 15-pin D-Sub-HD socket and open cable
end to connect the CLV to the supply system device.
2. Following operating voltages/power output
–AMV 40-011: 24 V DC
±
20 %, according to IEC 742, min. 10 W
–AMS 40-013: 230 V AC
±
10 % 50 Hz
–AMS 40-012: 115 V AC
±
10 % 50/60 Hz
–AMV 100-011: 10 ... 30 V DC according to IEC 742
–AMV 200-011: 10 ... 30 V DC according to IEC 742
3. In the case of external reading pulsing via the "Sensor 1" switching input: A suitable
reading pulse sensor for signaling an object with bar code, for example, a photoelectric
reflex switch.
4. In the case of detection of the object distance via the "Sensor 2" switching input:
A suitable sensor for 2-stage focal position changeover, for example a photoelectric re-
flex switch.
5. A higher-level computer (host) with a data interface of type RS 422/485 or RS 232.
6. An optional interface converter No. 2 020 825 for installation in the AMV/S 40
connection module in order to connect the CLV to a 20 mA data interface.
7. A PC (al least 80486, 66 MHz, 16 MB RAM, CD-ROM drive, serial interface, mouse
(recommended)) with Windows 95
TM
/98
TM
, Windows NT
TM
or Windows XP
TM
.
8. An RS-232 data connection cable with two 9-pin D-Sub sockets for connecting the PC
to the terminal interface of the CLV in the AMV/S 40 connection module,
e. g. No. 2 014 054. Pin 2 (RxD) and Pin 3 (TxD) are transposed.
9. An HTML browser for using the "CLV-Setup Help" online help system, e. g. Netscape
Navigator
TM
or the enclosed browser I-ViewPro
TM
(refer to
Chapter 3.1.1 Scope of deli-
very, Page 3-1
).
10. For connection of the CLV to the Interbus S, the Profibus DP, DeviceNet or the Ethernet:
the corresponding BMV/BMH 10 Bus Connection Module (on request).
11. For connection of the CLV to the CAN Scanner Network: the Operating Instructions
“Application of the CAN interface“ (no. 8 009 180, English edition)
