Mounting
34 © SICK AG • Subject to change without notice • 8024484/2019-06-06
2
Set
Esc
<
<

3
Fig. 14: Mounting the distance measuring device
1 Knurled screw
2 Alignment bracket
3 Distance measuring device
4. Secure the distance measuring device with the knurled screw.
Set
Esc
<
<

Fig. 15: Securing the distance measuring device with knurled screw
1 Knurled screw
