SICK DL100 Pro

Operating the measuring device
48 © SICK AG • Subject to change without notice • 8024484/2019-06-06
“SSI” menu
(continued)
Parameters Description
E-bit
(error bit)
Select error bit function.
The parameter is only displayed if the “Gry24E” or “Bin24E”
option is selected for the “Coding” parameter.
The error bit is selected if the option has been activated and
thecaseoccurs.Youcanactivate(On)ordeactivate(O)multi-
ple options. The error bit is set to “1” if there is a warning.
Options
• WmLsr: Measuring device is nearly due to be replaced due
to the aging of the laser.
• WrnLev: Level < LevelMin: Required attenuation value was
undercut.
• WrnTemp: Temperature is outside the limits.
• WmPlb: Measured value is not plausible.
• MF1: MF1 active
• MF2: MF2 active
Factory setting
• ll options are deactivated.
ResDst Select the resolution for the output value in mm using the dig-
ital data interface or select a freely adjustable resolution. The
measured value is multiplied by the resolution. The parameter
doesnothaveanyinuenceonthemeasuredvalueshownon
the display.
Options
• 0.1
• 0.125
• 1.0
• 10.0
• 100.0
• freRes
Factory setting
• 0.1
freRes • Selectresolutioninμm(micrometer)ifthe“freRes”value
was selected in the “ResDst” parameter.
Adjustment range
1...100,000μm
Factory setting
100μm
Table 14: “SSI” menu
