SICK DL100 Pro User Manual

Table of contents
6 © SICK AG • Subject to change without notice • 8024484/2019-06-06
10.3.6 Module 6: “Time/i4w, Distance/i2w” .................... 89
10.3.7 Module 7: “Time/i4w, Distance/i2w/Speed/
i2w” .......................................................................... 90
10.3.8 Module 10: “Status/i2b, Control/o2b” ................. 92
10.3.9 Module 13: “Temp/i1b, Level/i2b, Hrs/i2b” ......... 94
10.3.10 Module 20: “MFx” ................................................... 95
10.3.11 Module 22: “Setup Preset Static”........................ 100
10.3.12 Module23:“SetupOset” ................................... 100
10.3.13 Module 25: "Special Functions” .......................... 100
10.3.14 Module 26: “SSI” .................................................. 102
10.3.15 Module 30: “Serial No/i8b“ ................................. 105
10.3.16 Module 31: "Product Code/i9w” .......................... 105
10.3.17 Module 32: “Version HW/i8b” ............................. 105
10.3.18 Module 33: "Version FPGA/i10w” ....................... 106
10.3.19 Module 34: "Version uC/i10w” ............................ 106
10.3.20 Module 35: “Version uC2/i10w” ......................... 107
10.4 “Preset” – move to initialization position ............................ 107
11 “SSI” interface ............................................................................... 109
11.1 Basics .................................................................................... 109
11.2 SSI protocol (data format) ....................................................110
12 Cleaning and maintenance ...........................................................111
12.1 Cleaning ................................................................................ 111
12.2 Maintenance ......................................................................... 111
13 Troubleshooting .............................................................................112
13.1 LED status display ................................................................ 112
13.2 Warning messages ............................................................... 113
13.3 Error messages ..................................................................... 113
13.4 PROFINET IO error messages .............................................. 114
13.5 Returns .................................................................................. 115
13.6 Disposal ................................................................................. 115
14 Repair ..............................................................................................115

SICK DL100 Pro Specifications

General

Output	Analog
Operating Temperature	-10 °C to +50 °C
Light source	Laser
Output type	Analog
Supply voltage	10 V DC to 30 V DC
Housing material	Plastic
Connection type	M12 connector
Power consumption	≤ 3 W
