SICK Flexi Classic User Manual

Operating Instructions Chapter 10
Flexi Classic Gateways
8011834/YT28/2016-03-15 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
131
Subject to change without notice
PROFINET IO Gateway
Data set 5
Read record
Location 1000-1061
Byte 1
MFD1
Byte 2
MFD2
Byte 3
MFD3
Byte 4
MFD4
Byte 5
MFD5
Byte 6
MFD6
Byte 7
MFD7
Byte 8
MFD8
Byte 9
MFD9
Byte 10
MFD10
Byte 11
MFD11
Byte 12
MFD12
Byte 13
MFD13
Byte 14
0
1)
Byte 15-18
MFCLASS1/CODE1, MFCLASS2/CODE2 (1)
Byte 19-22
MFCLASS1/CODE1, MFCLASS2/CODE2 (2)
Byte 23-26
MFCLASS1/CODE1, MFCLASS2/CODE2 (3)
Byte 27-30
MFCLASS1/CODE1, MFCLASS2/CODE2 (4)
Byte 31-34
MFCLASS1/CODE1, MFCLASS2/CODE2 (5)
Byte 35-38
MFCLASS1/CODE1, MFCLASS2/CODE2 (6)
Byte 39-42
MFCLASS1/CODE1, MFCLASS2/CODE2 (8)
Byte 43-46
MFCLASS1/CODE1, MFCLASS2/CODE2 (9)
Byte 47-50
MFCLASS1/CODE1, MFCLASS2/CODE2 (10)
Byte 51-54
MFCLASS1/CODE1, MFCLASS2/CODE2 (11)
Byte 55-58
MFCLASS1/CODE1, MFCLASS2/CODE2 (12)
Byte 59-62
MFCLASS1/CODE1, MFCLASS2/CODE2 (13)
Length
62 Bytes
1)
Inserted for byte alignment.
Tab.
116
:
Data set 5 of the
UE4100EN
