102 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Installation Interface Unit
Fig. 58 Fitting the weatherproof cover on the installation plate
4 Also screw the Interface Unit to the installation plate through the four holes of the
weatherproof cover using the supplied assembly material, → Fig. 59.
Detail
Detail
5
43
1
2
1 Installation plate
2 Weatherproof cover
3 Screw M8 DIN912
4 Washer A 8,4 DIN125
5 Nut M8 DIN934
