134 FLOWSIC100 Flare-XT · Operating Instructions · 8023761/V 1-0/2020-10 · © SICK Engineering GmbH
Commissioning FLOWSIC100 Flare-XT
If the quantity of flow rate N
2
is known, FLOWSIC100 Flare-XT can subtract this portion
from the total quantity. Without this compensation, the purge air share with the measured
molar mass of the combustible gases would be added to the total quantity of CO
2
which
leads to higher CO
2
emission values.
Fig. 88 Function of nitrogen compensation
In the Setup wizard, you can select whether the nitrogen quantity should be configured as a
constant value or read in via an analog input.
Fig. 89 Nitrogen compensation
