ß
LEDs on the control panel
à
Teachpushbutton
Additional information
Meaning of the LEDs: see "LED indicators and error indicators", page 83
3.9 Inputs
3.9.1 Switching inputs on the receiver
You can assign the following switching input functions:
Teach-in
Standby
Triggering RS485 data output
Additional information
SOPAS general settings, PIN configuration: see "“General Device Settings” page",
page 63
SOPAS digital configuration: see "“Digital configuration” menu", page 75
3.9.2 Test input on the sender
The test input can be used to switch off the sender. This simulates a complete blocking
of the beams. This makes it possible to test the behavior of the switching or analog out‐
puts that have been configured accordingly.
3.10 Application examples
3.10.1 MLG2 application examples
The MLG-2 is suitable for optical and non-contact edge detection and width and center
calculation of flexible and rigid sheets of material. It can detect up to 10 edges. 10
functions can be calculated from this. These can be centers or widths. The material can
be opaque or partially transparent with a transmission of up to 80%.
Table 8: Application examples for the MLG-2
Figure 9: Automobile industry, position detec‐
tion of rubber bands
Figure 10: Automobile industry, position detec‐
tion of material rolls
3 PRODUCT DESCRIPTION
20
O P E R A T I N G I N S T R U C T I O N | MLG-2 WebChecker 8024643/2019-09-02 | SICK
Subject to change without notice
