SICK WebChecker MLG-2 User Manual

Table 4: Measurement field width
Position 8 - 11 Meaning Type code specification -
Number which can be ordered
8 No selection –
9
Number of measurement modules
on the connection side of the MLG-2
(left)
1: 1 measurement module
2: 2 measurement modules
…
9: 9 measurement modules
A: 10 measurement modules
…
G: 16 measurement modules
10
Number of empty modules 0: 0 empty modules
1: 1 empty module
2: 2 empty modules
...
9: 9 empty modules
A: 10 empty modules
...
J: 19 empty modules
11
Number of measurement modules
on the head side of the MLG-2 (right)
0: 0 measurement modules
1: 1 measurement module
…
9: 9 measurement modules
A: 10 measurement modules
…
F: 15 measurement modules
Example calculation of measurement field width
•
Number of measurement modules on the connection side = 3
•
Number of empty modules = 1 piece
•
Number of measurement modules on the head side = 2
Measurement field width = (Number of measurement modules on the connection side
+ number of empty modules + number of measurement modules on the head side)
x 150 mm – 5 mm
Measurement field width = (3 measurement modules + 1 empty module +
2 measurement modules) x 150 mm – 5 mm
Measurement field width = (3 + 1 + 2) x 150 mm – 5 mm
Measurement field width = 895 mm
3.2.2 Combinations of MLG-2 inputs and outputs
Table 5: Possible combinations of MLG-2 inputs and outputs
Position 12 Inputs and outputs, data interface Connection type
B
•
2 × switching output (Q) and
•
2 x analog output (QA)
or
•
1 × input (IN) and
•
1 x switching output (Q) and
•
2 x analog output (QA)
M12, 8-pin, A-coded
PRODUCT DESCRIPTION 3
8024643/2019-09-02 | SICK O P E R A T I N G I N S T R U C T I O N | MLG-2 WebChecker
13
Subject to change without notice
