SICK WebChecker MLG-2 User Manual

rs
ca. 1/3
ca. 2/3
max. 2.5 m
2
2
1
Figure 25: Correct mounting
1
Operating range: Maximum possible distance between sender and receiver
2
Optimal object position, approximate specifications
Figure 26: Examples for incorrect mounting
5.3.1 Mounting the QuickFix bracket
CAUTION
Protruding screws!
Protruding screws could cause injuries.
b
Select the length of the M5 screws so that no injuries from protruding screw parts
are possible.
5 MOUNTING
34
O P E R A T I N G I N S T R U C T I O N | MLG-2 WebChecker 8024643/2019-09-02 | SICK
Subject to change without notice
