16.3 Dimensional drawings
16.3.1 Dimensional drawing for the MLG-2
M12; 8pol
Sender
Sender
Empfänger
Empfänger
30,6 30,6
273
192
M12; 4pol
5
62
1
M12; 5pol
216.2
13,5
15
34
5
15
34
2
3
4
6 6
Figure 70: MLG-2 dimensions
1
Measurement field width
2
Head side measurement field width
3
Blind zone
4
Connection side measurement field width
5
LED (light beam)
6
Status LEDs
