7SR11 & 7SR12 Settings & Instruments Guide
©2017 Siemens Protection Devices Limited Chapter 2 Page 11 of 20
Instrument
Description
ENERGY METERS
→to view
This is the sub-group that includes all the meters that are
associated with Energy TEST/RESET ► allows access to this sub-
group
Active Energy
Exp
0.00MWh
Imp
0.00MWh
Displays both imported and exported Active Energy
Reactive Energy
Exp 0.00MVArh
Imp 0.00MVArh
Displays both imported and exported Reactive Energy
WATTMETRIC METERS
→to view
This is the sub-group that includes all the meters that are
associated with Wattmetric TEST/RESET ► allows access to this
sub-group
Ires R 0.0xIn W
Pres 0.0 xIn W
Ires R Angle 0.0º
I0-V0 Angle 0.0º
The Wattmetric component of residual current
Wattmetric residual power
Compensated residual phase angle
Applied residual phase angle
DIRECTIONAL METERS
→to view
This is the sub-group that includes all the meters that are
associated with Directional elements TEST/RESET ► allows
access to this sub-group. Only on models that have the 67 option
P/F Dir (67)
------------------------------------------------------
No Dir, PhA Fwd, PhA Rev, PhB Fwd,
PhB Rev, PhC Fwd, PhC Rev
The appropriate values from the selection will be displayed.
Calc E/F Dir (67N)
------------------------------------------------------
No Dir, E/F Fwd, E/F Rev
The appropriate values from the selection will be displayed.
Meas E/F Dir (67G)
------------------------------------------------------
No Dir, E/F Fwd, E/F Rev
The appropriate values from the selection will be displayed.
SEF Dir (67SEF)
------------------------------------------------------
No Dir, SEF Fwd, SEF Rev
The appropriate values from the selection will be displayed.
THERMAL METERS
→to view
This is the sub-group that includes all the meters that are
associated with Thermal TEST/RESET ► allows access to this
sub-group
Thermal Status
Phase A 0.0%
Phase B 0.0%
Phase C 0.0%
Displays the thermal capacity
FREQUENCY METERS
→to view
This is the sub-group that includes all the meters that are
associated with Thermal TEST/RESET ► allows access to this
sub-group
Frequency 0.000Hz
Last Trip 0.000Hz
Displays the frequency
AUTORECLOSE METERS
→to view
This is the sub-group that includes all the meters that are
associated with Autoreclose TEST/RESET ► allows access to this
sub-group. Only seen on models that have the 79 option
Autoreclose Status
79 AR State
AR Close Shot 0
MAINTENANCE METERS
→to view
This is the sub-group that includes all the meters that are
associated with Maintenance TEST/RESET ► allows access to
this sub-group
CB Total Trips
Count 0
Target 100
Displays the number of CB trips experienced by the CB
