7SR11 & 7SR12 Description Of Operation
ยฉ2017 Siemens Protection Devices Limited Chapter 1 Page 85 of 88
6.7 Operating Mode
The relay has three operating modes, Local, Remote and Out of Service. The following table identifies the
functions operation in each mode.
The modes can be selected by the following methods:
SETTINGS MODE>SYSTEM CONFIG>Relay Mode setting, a Binary Input or Command
Table 6-1 Operating Mode
OPERATION
REMOTE MODE
LOCAL MODE
OUT OF SERVICE
MODE
Control
USB/Rear Ports set to REMOTE *
Enabled
Disabled
Disabled
Fascia (Control Mode)
Disabled
Enabled
Disabled
USB/Rear Ports set to LOCAL *
Disabled
Enabled
Disabled
Binary Inputs
Setting Option
Setting Option
Disabled
Binary Outputs
Enabled
Enabled
Disabled
Reporting
Spontaneous
IEC
Enabled
Enabled
Disabled
DNP
Enabled
Enabled
Disabled
General Interrogation
IEC
Enabled
Enabled
Disabled
DNP
Enabled
Enabled
Disabled
MODBUS
Enabled
Enabled
Disabled
Changing of Settings
USB/Rear Ports defined REMOTE *
Enabled
Disabled
Enabled
Fascia
Enabled
Enabled
Enabled
USB/Rear Ports defined as LOCAL *
Disabled
Enabled
Enabled
USB/Rear Ports defined LOCAL or
REMOTE *
Enabled
Enabled
Enabled
Historical Information
Waveform Records
Enabled
Enabled
Enabled
Event Records
Enabled
Enabled
Enabled
Fault Information
Enabled
Enabled
Enabled
Setting Information
Enabled
Enabled
Enabled
*Each Communication port has a setting to allow the user to determine which port is used for local operation and
which port is used for remote operation. If the port is set to Local or Remote, the port can be used for all
operations and has no priority.
The communication port modes can be selected at:
SETTINGS MODE>SYSTEM CONFIG>Communications
6.8 Control Mode
This mode provides convenient access to commonly used relay control and test functions. When any of the items
listed in the control menu are selected control is initiated by pressing the ENTER key. The user is prompted to
confirm the action, again by pressing the ENTER key, before the command is executed.
7SR1102-1*A12-*AA0 models with โ€˜Aโ€™ variant software do not support Control Mode.
Note that a CB must be in a Closed state before an Open command will be accepted. And that a CB must be in
an Open state before a Close command will be accepted. If not, the Relay reports that the requested command is
โ€˜Interlockedโ€™.
Note also that switching a protection function IN / OUT via the Control Menu will not change that functionโ€™s
ENABLED / DISABLED setting. The Control Menu selection will over-ride the setting, however.
Control Mode commands are password protected using the Control Password function โ€“ see Section 6.10.
