4.3 Point List
The information shown below is the default configuration. This can be modified using the Communications
Configuration Editor tool, refer section 9 for details.
4.3.1 Coils (Read Write Binary values)
Address Description
00001 Binary Output 1
00002 Binary Output 2
00003 Binary Output 3
00004 Binary Output 4
00005 Binary Output 5
00006 Binary Output 6
00007 Binary Output 7
00008 Binary Output 8
00101 Setting G1 selected
00102 Setting G2 selected
00103 Setting G3 selected
00104 Setting G4 selected
00109 CB 1
00112 Auto-reclose active
00113 HotLine Working
00114 E/F Out
00115 SEF Out
00116 Inst Protection Out
00155 Remote Mode
00156 Out Of Service Mode
00157 Local Mode
00158 Local & Remote
00165 Reset Start Count
00180 CB 1 Opened
00181 CB 1 Closed
00200 User SP Command 1
00201 User SP Command 2
00202 User SP Command 3
00203 User SP Command 4
00204 User SP Command 5
00205 User SP Command 6
00206 User SP Command 7
00207 User SP Command 8
00208 User DP Command 1
00209 User DP Command 2
00210 User DP Command 3
00211 User DP Command 4
00212 User DP Command 5
00213 User DP Command 6
00214 User DP Command 7
