7SR120 Technical Manual
Chapter 4 - Page 40 of 84 © 2017 Siemens Protection Devices Limited
Address Description
10910 User DP Command 3
10911 User DP Command 4
10912 User DP Command 5
10913 User DP Command 6
10914 User DP Command 7
10915 User DP Command 8
10916 32-1
10917 32-2
10918 32S-1
10919 32S-2
10920 55-1
10921 55-2
11073 CB DBI
11074 CB Travelling
11075 Close CB Failed
11076 Open CB Failed
11077 Start Count Alarm
11078 50AFD PhA
11079 50AFD PhB
11080 50AFD PhC
11081 50AFD
11082 AFD Zone 1 Flash
11083 AFD Zone 1
11084 AFD Zone 2 Flash
11085 AFD Zone 2
11086 AFD Zone 3 Flash
11087 AFD Zone 3
11088 AFD Zone 4 Flash
11089 AFD Zone 4
11090 AFD Zone 5 Flash
11091 AFD Zone 5
11092 AFD Zone 6 Flash
11093 AFD Zone 6
4.3.3 Input Registers (Read Only Registers)
Address Description Format Mult Description
30001 Event Count EVENTCOUNT 0.000000 Events Counter
30002 Event EVENT 0.000000 8 Registers
30010 Vab Primary FP_32BITS_3DP 1.000000 Vab V
30012 Vbc Primary FP_32BITS_3DP 1.000000 Vbc V
30014 Vca Primary FP_32BITS_3DP 1.000000 Vca V
30016 Va Primary FP_32BITS_3DP 1.000000 Va V
30018 Vb Primary FP_32BITS_3DP 1.000000 Vb V
30020 Vc Primary FP_32BITS_3DP 1.000000 Vc V
30022 Va Secondary FP_32BITS_3DP 1.000000 Va V
30024 Vb Secondary FP_32BITS_3DP 1.000000 Vb V
30026 Vc Secondary FP_32BITS_3DP 1.000000 Vc V
