7SR120 Technical Manual
Chapter 4 - Page 14 of 84 © 2017 Siemens Protection Devices Limited
3.4 Point List
The following sub-sections contain tables listing the data points available via the IEC60870-5-103 protocol.
The information shown below is the default configuration. This can be modified using the Communications
Configuration Editor tool, refer section 9 for details.
The information shown below is the default configuration. This can be modified using the Communications
Configuration Editor tool, refer section 9 for details.
3.4.1 Event Function (FUN) & Information (INF) Numbers
The following Event EVT and INF numbers apply to this device.
FUN INF Description ASDU COT
1 SE, GI
60 4 Remote Mode
20 Ack, Nak
1 SE, GI
60 5 Out Of Service Mode
20 Ack, Nak
1 SE, GI
60 6 Local Mode
20 Ack, Nak
1 SE, GI
60 7 Local & Remote
20 Ack, Nak
60 12 Control Received 1 SE
60 13 Command Received 1 SE
60 128 Cold Start 1 SE
60 129 Warm Start 1 SE
60 130 Re-Start 1 SE
60 131 Expected Restart 1 SE, GI
60 132 Unexpected Restart 1 SE, GI
1 SE
60 133 Reset Start Count
20 Ack, Nak
60 135 Trigger Storage 1 SE
60 136 Clear Waveform Records 1 SE
60 137 Clear Fault Records 1 SE
60 138 Clear Event Records 1 SE
1 SE
60 140 Demand metering reset
20 Ack, Nak
60 170 General Alarm 1 1 SE, GI
60 171 General Alarm 2 1 SE, GI
60 172 General Alarm 3 1 SE, GI
60 173 General Alarm 4 1 SE, GI
60 174 General Alarm 5 1 SE, GI
60 175 General Alarm 6 1 SE, GI
60 182 Quick Logic E1 1 SE, GI
60 183 Quick Logic E2 1 SE, GI
60 184 Quick Logic E3 1 SE, GI
60 185 Quick Logic E4 1 SE, GI
70 5 Binary Input 5 1 SE, GI
70 6 Binary Input 6 1 SE, GI
75 1 Virtual Input 1 1 SE, GI
