Siemens 7SR12 Argus User Manual

Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 15 of 84
FUN INF Description ASDU COT
75 2 Virtual Input 2 1 SE, GI
75 3 Virtual Input 3 1 SE, GI
75 4 Virtual Input 4 1 SE, GI
75 5 Virtual Input 5 1 SE, GI
75 6 Virtual Input 6 1 SE, GI
75 7 Virtual Input 7 1 SE, GI
75 8 Virtual Input 8 1 SE, GI
1 SE, GI
80 1 Binary Output 1
20 Ack, Nak
1 SE, GI
80 2 Binary Output 2
20 Ack, Nak
1 SE, GI
80 3 Binary Output 3
20 Ack, Nak
1 SE, GI
80 4 Binary Output 4
20 Ack, Nak
1 SE, GI
80 5 Binary Output 5
20 Ack, Nak
1 SE, GI
80 6 Binary Output 6
20 Ack, Nak
1 SE, GI
80 7 Binary Output 7
20 Ack, Nak
1 SE, GI
80 8 Binary Output 8
20 Ack, Nak
90 1 LED 1 1 SE, GI
90 2 LED 2 1 SE, GI
90 3 LED 3 1 SE, GI
90 4 LED 4 1 SE, GI
90 5 LED 5 1 SE, GI
90 6 LED 6 1 SE, GI
90 7 LED 7 1 SE, GI
90 8 LED 8 1 SE, GI
90 9 LED 9 1 SE, GI
91 1 LED PU 1 1 SE, GI
91 2 LED PU 2 1 SE, GI
91 3 LED PU 3 1 SE, GI
91 4 LED PU 4 1 SE, GI
91 5 LED PU 5 1 SE, GI
91 6 LED PU 6 1 SE, GI
91 7 LED PU 7 1 SE, GI
91 8 LED PU 8 1 SE, GI
91 9 LED PU 9 1 SE, GI
160 2 Reset FCB 5 SE
160 3 Reset CU 5 SE
160 4 Start/Restart 5 SE
160 5 Power On 1 SE, GI
1 SE, GI
160 16 Auto-reclose active
20 Ack, Nak
160 19 LED Reset
1 SE
