7SR120 Technical Manual
Chapter 4 - Page 36 of 84 © 2017 Siemens Protection Devices Limited
Address Description
00215 User DP Command 8
4.3.2 Inputs (Read Only Binary values)
Address Description
10001 Binary Input 1
10002 Binary Input 2
10003 Binary Input 3
10004 Binary Input 4
10005 Binary Input 5
10006 Binary Input 6
10102 Remote Mode
10103 Out Of Service Mode
10104 Local Mode
10105 Local & Remote
10110 General Trip
10111 Trip Circuit Fail
10112 Start/Pick-up L1
10113 Start/Pick-up L2
10114 Start/Pick-up L3
10115 General Start/Pick-up
10116 VT Fuse Failure
10117 Earth Fault Forward/Line
10118 Earth Fault Reverse/Busbar
10119 Start/Pick-up N
10120 Fault Forward/Line
10121 Fault Reverse/Busbar
10122 51-1
10123 50-1
10124 51N-1
10125 50N-1
10126 51G-1
10127 50G-1
10128 51-2
10129 50-2
10130 51N-2
10131 50N-2
10132 51G-2
10133 50G-2
10134 51-3
10135 50-3
10136 51N-3
10137 50N-3
10138 51G-3
10139 50G-3
10140 51-4
10141 50-4
10142 51N-4
