Siemens 7SR12 Argus - Measurands; Disturbance Recorder Actual Channel (ACC) Numbers

Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 27 of 84
FUN INF Description ASDU COT
255 0 Time Synchronisation 6
Time
Synch.
3.4.2 Measurands
The following Measurand EVT and INF numbers apply to this device.
FUN INF Description ASDU COT
183 148
Measurand I
L1,2,3,
V
L1,2,3,
P, Q, F, V
L1-2,L2-3,L3-1
---
I
L1
(2.4x) (Window 1%)
I
L2
(2.4x) (Window 1%)
I
L3
(2.4x) (Window 1%)
V
L1
(1.2x) (Window 1%)
V
L2
(1.2x) (Window 1%)
V
L3
(1.2x) (Window 1%)
P (2.4x) (Window 1%)
Q (2.4x) (Window 1%)
F (1.2x) (Window 0.1%)
V
L1-2
(1.2x) (Window 1%)
V
L2-3
(1.2x) (Window 1%)
V
L3-1
(1.2x) (Window 1%)
9
Cyclic -
Refresh
rate 5
seconds
or value
change
greater
than
Window x
%.
183 236
Measurand Max I
a,b,c,
V
an,bn,cn,
P, Q, V
ab,bc,ca
---
Ia Max (2.4x) (Window 1%)
Ib Max (2.4x) (Window 1%)
Ic Max (2.4x) (Window 1%)
Van Max
1
(1.2x) (Window 1%)
Vbn Max
2
(1.2x) (Window 1%)
Vcn Max
3
(1.2x) (Window 1%)
P Max (2.4x) (Window 1%)
Q Max (2.4x) (Window 1%)
Vab Max (1.2x) (Window 1%)
Vbc Max (1.2x) (Window 1%)
Vca Max (1.2x) (Window 1%)
9
Cyclic -
Refresh
rate 5
seconds
or value
change
greater
than
Window x
%.
3.4.3 Disturbance Recorder Actual Channel (ACC) Numbers
The following Disturbance Recorder channel numbers apply to this device.
FUN ACC Description
182 1 V1
182 2 V2
182 3 V3
182 5 Ia
182 6 Ib
182 7 Ic
182 8 Ig1
