Siemens 7SR12 Argus User Manual

7SR11 & 7SR12 Performance Specification
©2017 Siemens Protection Devices Limited Chapter 3 Page 48 of 56
2.20 64H Restricted Earth Fault Protection
2.20.1 Reference
Parameter Value
Is
Setting
SEF Input
0.005, 0.006 … 0.100, 0.105 … 0.950 xIn
EF Input
0.05, 0.055.… 0.95 xIn
t
d
Delay setting
0.00, 0.01…20.00, 20.10… 100, 101… 1000, 1010…
10000, 10100… 14400 s
2.20.2 Operate and Reset Level
Attribute Value
I
op
Operate level
100 % Is, ± 5 % or ±1% xIn
Reset level
95 % I
op
, ± 5 % or ±0.1% xIn
Repeatability
± 1 %
Transient overreach
(X/R ≤ 100)
≤ -5 %
Variation
-10 °C to +55 °C
≤ 5 %
f
nom
± 5 %
≤ 5 %
2.20.3 Operate and Reset Time
Attribute Value
t
basic
Element basic operate time
0 to 2 xIs, 45 ms, ± 10ms
0 to 5 xIs, 35 ms, ± 10ms
t
op
Operate time following delay
t
basic
+ t
d
, ± 1% or ± 10ms
Repeatability
± 1% or ± 10ms
Overshoot time < 40 ms
Disengaging time < 50 ms
