7SR120 Technical Manual
Chapter 4 - Page 26 of 84 © 2017 Siemens Protection Devices Limited
FUN INF Description ASDU COT
185 114 CB Wear CB B Remaining 0 SE
185 115 CB Wear CB C Remaining 0 SE
185 241 Start Count Alarm 0 SE, GI
186 1 50AFD PhA 0 SE, GI
186 2 50AFD PhB 0 SE, GI
186 3 50AFD PhC 0 SE, GI
186 4 50AFD 0 SE, GI
186 5 AFD Zone 1 Flash 0 SE, GI
186 6 AFD Zone 1 0 SE, GI
186 7 AFD Zone 2 Flash 0 SE, GI
186 8 AFD Zone 2 0 SE, GI
186 9 AFD Zone 3 Flash 0 SE, GI
186 10 AFD Zone 3 0 SE, GI
186 11 AFD Zone 4 Flash 0 SE, GI
186 12 AFD Zone 4 0 SE, GI
186 13 AFD Zone 5 Flash 0 SE, GI
186 14 AFD Zone 5 0 SE, GI
186 15 AFD Zone 6 Flash 0 SE, GI
186 16 AFD Zone 6 0 SE, GI
186 17 AFD Zone1 Count 0 SE
186 18 AFD Zone2 Count 0 SE
186 19 AFD Zone3 Count 0 SE
186 20 AFD Zone4 Count 0 SE
186 21 AFD Zone5 Count 0 SE
186 22 AFD Zone6 Count 0 SE
200 1 CB 1 0 SE
200 6 CB 1 Opened 0 SE, GI
200 7 CB 1 Closed 0 SE, GI
200 150 User SP Command 1 0 SE, GI
200 151 User SP Command 2 0 SE, GI
200 152 User SP Command 3 0 SE, GI
200 153 User SP Command 4 0 SE, GI
200 154 User SP Command 5 0 SE, GI
200 155 User SP Command 6 0 SE, GI
200 156 User SP Command 7 0 SE, GI
200 157 User SP Command 8 0 SE, GI
200 158 User DP Command 1 0 SE
200 159 User DP Command 2 0 SE
200 160 User DP Command 3 0 SE
200 161 User DP Command 4 0 SE
200 162 User DP Command 5 0 SE
200 163 User DP Command 6 0 SE
200 164 User DP Command 7 0 SE
200 165 User DP Command 8 0 SE
200 200 CB 1 Trip & Reclose 0 SE
200 201 CB 1 Trip & Lockout 0 SE
200 255 Blocked By Interlocking 0 SE, GI
255 0 General Interrogation (GI) Initiation 7 Init. GI
255 0 General Interrogation (GI) End 8 End of GI
