7SR120 Technical Manual
Chapter 4 - Page 24 of 84 © 2017 Siemens Protection Devices Limited
FUN INF Description ASDU COT
183 82 27/59-2 0 SE, GI
183 83 27/59-3 0 SE, GI
183 84 27/59-4 0 SE, GI
183 85 59NIT 0 SE, GI
183 86 59NDT 0 SE, GI
183 90 81-1 0 SE, GI
183 91 81-2 0 SE, GI
183 92 81-3 0 SE, GI
183 93 81-4 0 SE, GI
183 96 81HBL2 0 SE, GI
183 100 CB Alarm 0 SE, GI
183 101 Trip Circuit Fail 1 0 SE, GI
183 102 Trip Circuit Fail 2 0 SE, GI
183 103 Trip Circuit Fail 3 0 SE, GI
183 114 Close CB Failed 0 SE, GI
183 115 Open CB Failed 0 SE, GI
183 116 Reclaim 0 SE, GI
183 117 Lockout 0 SE, GI
183 119 Successful DAR Close 0 SE
183 120 Successful Man Close 0 SE
183 121 HotLine Working 0 SE, GI
183 122 Inst Protection Out 0 SE, GI
183 123 CB Total Trip Count 0 SE, GI
183 124 CB Delta Trip Count 0 SE, GI
183 125 CB Count To AR Block 0 SE, GI
183 126 Reset CB Total Trip Count 0 SE
183 127 Reset CB Delta Trip Count 0 SE
183 128 Reset CB Count To AR Block 0 SE
183 129 I^2t CB Wear 0 SE, GI
183 130 Reset I^2t CB Wear 0 SE
183 131 79 AR In progress 0 SE, GI
183 132 CB Frequent Ops Count 0 SE, GI
183 133 Reset CB Frequent Ops Count 0 SE
183 137 CB on by auto reclose 0 SE, GI
183 140 Cold Load Active 0 SE, GI
183 141 P/F Inst Protection Inhibited 0 SE, GI
183 142 E/F Inst Protection Inhibited 0 SE, GI
183 143 SEF Inst Protection Inhibited 1 SE, GI
183 144 Ext Inst Protection Inhibited 0 SE, GI
183 163 Trip Time Alarm 0 SE
183 164 Close Circuit Fail 1 0 SE, GI
183 165 Close Circuit Fail 2 0 SE, GI
183 166 Close Circuit Fail 3 0 SE, GI
183 167 Close Circuit Fail 0 SE, GI
183 171 60 CTS-I 0 SE, GI
183 172 Act Energy Exp 0 SE
183 173 Act Energy Imp 0 SE
183 174 React Energy Exp 0 SE
183 175 React Energy Imp 0 SE
