Siemens 7SR12 Argus User Manual

7SR120 Technical Manual
Chapter 4 - Page 42 of 84 © 2017 Siemens Protection Devices Limited
Address Description Format Mult Description
30134 S (3P) FP_32BITS_3DP 0.000001 3 Phase VA
30136 Power Factor A FP_32BITS_3DP 1.000000 Phase A
30138 Power Factor B FP_32BITS_3DP 1.000000 Phase B
30140 Power Factor C FP_32BITS_3DP 1.000000 Phase C
30142 Power Factor(3P) FP_32BITS_3DP 1.000000 3 Phase
30144 Act Energy Exp UINT32 1.000000 Act Energy Exp
30146 Act Energy Imp UINT32 1.000000 Act Energy Imp
30148 React Energy Exp UINT32 1.000000 React Energy Exp
30150 React Energy Imp UINT32 1.000000 React Energy Imp
30152 Thermal Status Ph A UINT16 1.000000 Thermal Status Ph A %
30153 Thermal Status Ph B UINT16 1.000000 Thermal Status Ph B %
30154 Thermal Status Ph C UINT16 1.000000 Thermal Status Ph C %
30167 Fault Records UINT16 1.000000 Fault Records
30168 Event Records UINT16 1.000000 Event Records
30169 Waveform Records UINT16 1.000000 Waveform Records
30170 Vab Secondary FP_32BITS_3DP 1.000000 Vab V
30172 Vbc Secondary FP_32BITS_3DP 1.000000 Vbc V
30174 Vca Secondary FP_32BITS_3DP 1.000000 Vca V
30176 Vn Primary FP_32BITS_3DP 1.000000 Vn V
30178 Vn Secondary FP_32BITS_3DP 1.000000 Vn V
30180 Vn Secondary FP_32BITS_3DP 1.000000 Vn Degrees
30193 I Phase A Max FP_32BITS_3DP 1.000000 Ia Max Demand
30195 I Phase B Max FP_32BITS_3DP 1.000000 Ib Max Demand
30197 I Phase C Max FP_32BITS_3DP 1.000000 Ic Max Demand
30199 P 3P Max FP_32BITS_3DP 0.000001 Power Max Demand
30201 Q 3P Max FP_32BITS_3DP 0.000001 VARs Max Demand
30207 Isef Primary FP_32BITS_3DP 1.000000 Isef A
30209 Isef Secondary FP_32BITS_3DP 1.000000 Isef A
30211 Isef Nominal FP_32BITS_3DP 1.000000 Isef xInom
30241 CB Total Trip Count UINT32 1.000000 CB Total Trip Count
30243 CB Delta Trip Count UINT32 1.000000 CB Delta Trip Count
30245 CB Count To AR Block UINT32 1.000000 CB Count to AR Block
30247 CB Frequent Ops Count UINT32 1.000000 CB Frequent Ops Count
30301 Ia Last Trip FP_32BITS_3DP 1.000000 Ia Fault
30303 Ib Last Trip FP_32BITS_3DP 1.000000 Ib Fault
30305 Ic Last Trip FP_32BITS_3DP 1.000000 Ic Fault
30307 Va Last Trip FP_32BITS_3DP 1.000000 Va Fault
30309 Vb Last Trip FP_32BITS_3DP 1.000000 Vb Fault
30311 Vc Last Trip FP_32BITS_3DP 1.000000 Vc Fault
30313 In Last Trip FP_32BITS_3DP 1.000000 In Fault
30315 Ig Last Trip FP_32BITS_3DP 1.000000 Ig Fault
30317 Isef Last Trip FP_32BITS_3DP 1.000000 Isef Fault
30319 V Phase A Max FP_32BITS_3DP 1.000000 Va Max Demand
30321 V Phase B Max FP_32BITS_3DP 1.000000 Vb Max Demand
30323 V Phase C Max FP_32BITS_3DP 1.000000 Vc Max Demand
30325 V Phase AB Max FP_32BITS_3DP 1.000000 Vab Max Demand
30327 V Phase BC Max FP_32BITS_3DP 1.000000 Vbc Max Demand
30329 V Phase CA Max FP_32BITS_3DP 1.000000 Vca Max Demand
30341 LED1-n BITSTRING 0.000000 Led 1-16 status
