Siemens 7SR12 Argus User Manual

7SR120 Technical Manual
Chapter 4 - Page 48 of 84 © 2017 Siemens Protection Devices Limited
DNP V3.0
DEVICE PROFILE DOCUMENT
(Also see the DNP 3.0 Implementation Table in Section 5.2, beginning on page 50).
Unsolicited Notification Delay, (Configurable, default 5 seconds)
Unsolicited Response Retry Delay, (Configurable (between 3 - 9), default 5 seconds)
Unsolicited Offline Interval, (Configurable, default 30 seconds)
Binary Change Event Scan Period, (Polled, Not Applicable)
Double Bit Change Event Scan Period, (Polled - Not Applicable)
Analog Change Event Scan Period, (Polled - Not Applicable)
Counter Change Event Scan Period, (Polled - Not Applicable)
Frozen Counter Change Event Scan Period, (Polled - Not Applicable)
String Change Event Scan Period, (Unsupported - Not Applicable)
Virtual Terminal Event Scan Period, (Unsupported - Not Applicable)
Sends/Executes Control Operations:
WRITE Binary Outputs
Never Always Sometimes Configurable
SELECT/OPERATE
Never Always Sometimes Configurable
DIRECT OPERATE
Never Always Sometimes Configurable
DIRECT OPERATE - NO ACK
Never Always Sometimes Configurable
Count > 1
Never Always Sometimes Configurable
Pulse On
Never Always Sometimes Configurable
Pulse Off
Never Always Sometimes Configurable
Latch On
Never Always Sometimes Configurable
Latch Off
Never Always Sometimes Configurable
Queue
Never Always Sometimes Configurable
Clear Queue
Never Always Sometimes Configurable
Attach explanation if “Sometimes” or “Configurable” was checked for any operation.
Reports Binary Input Change Events when no specific
variation requested:
Never
Only time-tagged
Only non-time-tagged
Configurable to send one or the other
Reports time-tagged Binary Input Change Events when
no specific variation requested:
Never
Binary Input Change With Time
Binary Input Change With Relative Time
Configurable
Sends Unsolicited Responses:
Never
Configurable
Only certain objects
Sometimes (attach explanation)
ENABLE/DISABLE UNSOLICITED
Function codes supported
Sends Static Data in Unsolicited Responses:
Never
When Device Restarts
When Status Flags Change
No other options are permitted.
Default Counter Object/Variation:
No Counters Reported
Configurable
Default Object
Default Variation: _____
Point-by-point list attached
Counters Roll Over at:
No Counters Reported
Configurable (attach explanation)
16 Bits
32 Bits
Other Value: _____
Point-by-point list attached
Sends Multi-Fragment Responses:
Yes
No
Configurable
Sequential File Transfer Support:
