Chapter 4 - 7SR120 · Data Communications Definitions

Binary Output Status Points

Static (Steady-State) Object Number: 10

Change Event Object Number: 11

Control Relay Output Blocks (CROB) Object Number: 12

Binary Output Command Event Object Number: 13

Static Variation reported when variation 0 requested: 1 (Binary Output w/o status)

or 2 (Binary Output with status)

Change Event Variation reported when variation 0 requested: 1 (Binary Output Event w/o Time)

or 2 (Binary Output Event with Time)

Command Event Variation reported when variation 0 requested: 1 (Command Status w/o Time)

or 2 (Command Status with Time)

Point

Index

Description

Default

Change

Event

Assigned

Class

(1, 2, 3

or none)

Default

Variation

Static

Object 10

Default

Variation

Event

Object 11

Default

Command

Event

Object 13

Assigned

Class

(1, 2, 3

or none)

Default

Variation

Command

Event

Object 13

CROB

Supported

Operations

Default

CROB

Operations

CB 1 Trip & Lockout, write

only location.

0 2 2 0 1

Pulse On

Latch On

Pulse On

Demand metering reset,

write only location.

0 2 2 0 1

Pulse On

Latch On

Pulse On

87 Reset Energy Meters 0 2 2 0 1

Pulse On

Latch On

Pulse On

88 Remote mode 0 2 2 0 1

Pulse On

Latch On

Pulse On

89 Service mode 0 2 2 0 1

Pulse On

Latch On

Pulse On

90 Local mode 0 2 2 0 1

Pulse On

Latch On

Pulse On

91 Local & Remote 0 2 2 0 1

Pulse On

Latch On

Pulse On

98 Reset Start Count (Action) 0 2 2 0 1

Pulse On

Latch On

Pulse On

Latch On

99 User SP Command 1. 0 2 2 0 1

Pulse On

Latch On

Pulse On

100 User SP Command 2. 0 2 2 0 1

Pulse On

Latch On

Pulse On

101 User SP Command 3. 0 2 2 0 1

Pulse On

Latch On

Pulse On

102 User SP Command 4. 0 2 2 0 1

Pulse On

Latch On

Pulse On

103 User SP Command 5. 0 2 2 0 1

Pulse On

Latch On

Pulse On

104 User SP Command 6. 0 2 2 0 1

Pulse On

Latch On

Pulse On

105 User SP Command 7. 0 2 2 0 1

Pulse On

Latch On

Pulse On
