Siemens 7SR12 Argus User Manual

Chapter 4 - 7SR120 · Data Communications Definitions
© 2017 Siemens Protection Devices Limited Chapter 4 - Page 71 of 84
Analog Inputs
Static (Steady-State) Object Number: 30
Change Event Object Number: 32
Analog Input Deadband: 34
Static Variation reported when variation 0 requested: 1 (32-Bit Analog Input with Flag)
or 2 (16-Bit Analog Input with Flag)
or 3 (32-Bit Analog Input w/o Flag)
or 4 (16-Bit Analog Input w/o Flag)
or 5 (Single Precision, floating point Analog Input with Flag)
Change Event Variation reported when variation 0 requested: 1 (32-Bit Analog Change Event w/o Time)
or 2 (16-Bit Analog Input w/o Time)
or 3 (32-Bit Analog Input with Time)
or 4 (16-Bit Analog Input with Time)
or 5 (Single Precision, floating point Analog Input w/o Time)
or 7 (Single Precision, floating point Analog Input with Time)
Analog Input Reporting Deadband Variation reported when variation 0 requested: 1 (16-Bit)
or 2 (32-Bit)
or 3 (Single Precision, floating point)
Point
Index
Description
Default
Change Event
Assigned Class
(1, 2, 3 or none)
Default
Variation
Static
Object 30
Default
Variation
Event
Object 32
Default
Multiplier
Default
Deadband
111 P 3P Max 0,3 2 4 0.000 1000000.000
112 Q 3P Max 0,3 2 4 0.000 1000000.000
115 Isef Primary 0,3 2 4 1.000 10.000
116 Isef Secondary 0,3 2 4 1000.000 0.050
117 Isef Nominal 0,3 2 4 1000.000 0.050
135 CB Total Trip Count 0,3 1 3 1.000 1.000
136 CB Delta Trip Count 0,3 1 3 1.000 1.000
137 CB Count To AR Block 0,3 1 3 1.000 1.000
138 CB Frequent Ops Count 0,3 1 3 1.000 1.000
165 Ia Last Trip 0,3 1 3 1.000 Disabled
166 Ib Last Trip 0,3 1 3 1.000 Disabled
167 Ic Last Trip 0,3 1 3 1.000 Disabled
168 Va Last Trip 0,3 1 3 1.000 Disabled
169 Vb Last Trip 0,3 1 3 1.000 Disabled
170 Vc Last Trip 0,3 1 3 1.000 Disabled
171 In Last Trip 0,3 1 3 1.000 Disabled
172 Ig Last Trip 0,3 1 3 1.000 Disabled
173 Isef Last Trip 0,3 1 3 1.000 Disabled
174 V Phase A Max 0,3 2 4 0.010 100.000
175 V Phase B Max 0,3 2 4 0.010 100.000
176 V Phase C Max 0,3 2 4 0.010 100.000
177 V Phase AB Max 0,3 2 4 0.010 100.000
178 V Phase BC Max 0,3 2 4 0.010 100.000
179 V Phase CA Max 0,3 2 4 0.010 100.000
184 CB Wear A 0,3 1 3 0.000 1000000.000
185 CB Wear B 0,3 1 3 0.000 1000000.000
186 CB Wear C 0,3 1 3 0.000 1000000.000
187 CB Wear A Remaining 0,3 1 3 1.000 1.000
188 CB Wear B Remaining 0,3 1 3 1.000 1.000
189 CB Wear C Remaining 0,3 1 3 1.000 1.000
190 CB Wear Minimum 0,3 1 3 1.000 1.000
192 Freq Last Trip 0,3 5 7 1.000 1.000
196 Frequency Max 0,3 2 4 100.000 1.000
