FS20 Marine F
ire Dete
c
ti
on Control Pa
nel
109
Siemens Indus
try, I
nc.
A6V
10519176_enUS_b
Building T
echnologies
Division
Setting
the Devi
ce Add
ress
Address
Switch 1 (1)
Switch 2 (2)
Switch 3 (4)
Switch 4 (8)
0 (default)
OF
F
OFF
OFF
OF
F
Device 1
ON
OFF
OFF
OFF
Device 2
OFF
ON
OFF
OFF
Device 3
ON
ON
OFF
OFF
Device 4
OFF
OF
F
ON
OFF
Device 5
ON
OFF
ON
O
FF
Device 6
OFF
ON
ON
OFF
Device 7
ON
ON
ON
OFF
Device 8
OFF
OF
F
OFF
ON
Device 9
ON
OFF
OFF
ON
Device 10
OFF
ON
OFF
ON
Device 11
ON
ON
OFF
ON
Device 12
OFF
OFF
ON
ON
Device 13
ON
OFF
ON
ON
Device 14
OFF
ON
ON
ON
Device 15
ON
ON
ON
ON
Setting the Bau
d Rate
Baud rate [kb/
s]
Baud 0 / swit
ch 5
Baud 1 / swit
ch 6
9600
OFF
OFF
19200
ON
OFF
108
110
Table of Contents
Table of Contents
6
About this Document
11
Desigo Fire Safety User Documentation
12
Cerberus-PRO User Documentation
13
Safety
14
Safety Instructions
14
Safety Regulations for the Method of Operation
15
Standards and Directives Complied
17
FCC Statement
17
Release Notes
18
Description of FS20 Fire Alarm Control Panel
19
Introduction
19
Minimum Panel Requirement for Marine Application
19
Equipment Location
20
Software and Configuration
20
Planning a Fire Detection System
21
Detector Application
21
Intelligent/Analog Detectors
22
Detector Installation
23
Standard Structure of FS20 Panel
24
FH2071-UM Marine Enclosure
25
Installation
27
FCM2018-U2 / FCM2019-U2 / FCM2018-U3 / FCM2019-U3 / FCM2035-U2 / FCM2035-U3, Operating Units
28
Components on the Standard Operating Unit (FCM2018-U1)
29
Description
30
Mounting the Operating Unit
31
Wiring the Operating Unit
32
Inserting the Inscription Strips
33
View of Operating Unit & Main Board
34
Indicators
35
Adjustment Elements
36
Technical Data
37
Laying and Connecting the Power Supply
38
Overview of the Installation Procedure
38
Power Supply Location
40
Power Supply (170W) FP2011-U1
41
Laying and Connecting the Mains Cable for the Power Supply (170 W)
42
Installing the Electromagnetic Interference (EMI) Filter to Power Supply
43
Batteries
44
Install Batteries - BP-62
44
Install Wiring
46
Determining the Battery
47
FCI2016-U1 Periphery Board (252P)
48
Description
48
Views
50
Configuration Input Power and Battery
52
Wiring Specs
52
X301 Terminal Block - Power Supply 1
52
X305 Jumper - Power Supply On/Off
53
X303 Battery Terminal
53
FCI2017-U1 Periphery Board (504P)
54
Description
54
Views
56
Configuration Input Power and Battery
58
Wiring Specs
58
X301 Terminal Block - Power Supply 1
58
X305 Jumper - Power Supply 2 On/Off
59
X303 Battery Terminal
59
Periboard Installation, Wiring and Jumpers Set-Up
60
Installation of the Periphery Board
60
Notification Appliance Circuits
61
X601 Terminal Block
62
X602 Jumper
62
X603 Jumper
62
X604, X605, X606 Jumper
63
X403 Jumper
63
Bell Follower Input
63
Wiring Specs
63
Auxiliary 24VDC Output
64
Wiring Specs
64
X1001 Auxiliary Output Terminal Block
64
Relays
65
Wiring Specs
65
X1101 Relay Terminal Block
65
Detector Circuits
66
X1401 and X1801 Terminal Block
67
X1402 and X1802 Terminal Block
67
Indicators
68
Reset Buttons
68
S100 RESET Periphery Board
68
S1201 RESET Core 'A' Detector Circuit
68
S1601 RESET Core 'B' Detector Circuit
68
Technical Data
69
FCA2015-U1 Digital Alarm Communicator Transmitter (DACT)
71
Installation
72
FCA2015-U1 Format Description
73
Compatible Receivers / Formats
73
Compatible Alarm Communicator
74
FCA2015-U1 Event Codes
75
Installing DIN Rail FHA2031-U1
76
FN2001-U1 Network Module
78
Description
78
Installation
79
Installing the Shielding
80
Views
81
Pin Assignments
82
Connector X3
82
Configuring SAFEDLINK Interface -FN2001-U1
83
Indicators
84
Technical Data
85
FCA2016-U1 RS-485 Class 'A' Module
86
Description
86
Installation
87
Views
89
Pin Assignments
89
Plug X2
89
Technical Data
91
FCI2011-U1 NAC Module (1A/2B)
92
Description
92
Installation
93
Views
94
Pin Assignments for NAC 2
95
X5 NAC 2 Class a and NAC 2-1 and NAC 2-2 Class B Terminal Block
95
Adjusting Elements for NAC 2
96
X602 Jumper
96
X603 Jumper Degraded Mode Enable/Disable for NAC 2-2 Class B
96
X604, X605 and X606 NAC 2 Class A/B Selection Jumper
96
Technical Data
97
XCI2001-U1 Releasing Module
98
Description
98
Installation
99
Views
100
Pin Assignments for Releasing Module
101
X5 Plug Connection for Releasing Relay Output
101
Indicators
101
LED Indicators
101
Adjusting Elements for Releasing Module
102
Jumper X3, Degraded Mode Enable for Releasing
102
Technical Data
102
FT2014-U2/U3/R2/R3, FT2015-U2/U3/R2/R3 Remote Display Terminal
103
Description
103
Installation
104
Views
105
Wiring
106
X5/X6, RS-485 Circuit Connection Terminals
107
Adjustment Elements
108
Technical Data
110
Audible Alarms
111
Manual Initiating Devices
111
Remote Annunciators
112
Smoke Detectors
112
Spacing
112
Application Limitations
112
Thermal Detectors
112
Fixed Temperature
112
Rate Compensated
113
Spacing
113
Wiring Specifications for FS20 Fire
114
Typical Large FS20 Fire System Configuration
116
Power
116
Audible Alarms
116
Typical [Small] FS20 Fire System Configuration
116
Removing/Replacing Hardware Components
117
Uninstall
117
Commissioning
118
Preparing 'Panel' for Commissioning
118
Preparing the 'Panel' for Commission ~ Without Base Data Variant (BDV) Installation
119
Auto-Configuring 'Panel
119
Auto-Configuring the Detector Circuits
119
Commissioning with Manual Configuration
120
Commissioning with Manual Configuration and Auto-Configuration
121
Commissioning with Auto-Configuration Without a PC
123
Adding a 'Panel' to an Existing Site
123
Trouble Shooting
125
Temporarily Removing an Individual Base Device
125
Temporarily Removing Multiple Based Devices
126
Permanently Removing Based Devices
126
Preparation and Security
127
Equipment Lists for Marine Application
129
Desigo Channel
129
System
129
System Modules
129
Initiating Devices
129
Cerberus Pro Channel
130
System
130
System Modules
130
Initiating Devices
130
Common for both Desigo and Cerberus-Pro Channels
131
System Modules
131
Enclosure and Accessories
131
Peripherals and Specialized Devices
132
Conventional Devices
133
Notification Appliances
134
Installation Checklist
135
Appendix A: Inscription Strips Instructions
136
Installing Fonts
136
Entering/Changing Text
136
Fire Control Panel/Network Terminal, Without Releasing
137
Fire Control Panel/Network Terminal, with Releasing
138
Remote Terminal, Without Releasing
139
Additional Panel Labels
139
Remote Terminal, with Releasing
140
LED Indicator
141
Glossary
143
