FS20 Marine Fire Detection Control Panel
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
1.1 Desigo Fire Safety User Documentation
To access the Desigo Fire system user documentations, go to Siemens website:
http://iknow.us009.siemens.net/infolink/InfoLink.aspx?page=/infolink/Default.htm.
Enter the appropriate document number in the “Search” dialog box (see below) to access then
press “Find”.
Select the appropriate document by double-clicking it. It is recommended to save these documents
in your computer for future access. Select the “Save” button to store the document in your
computer.
Table 1: Desigo Fire Safety - User Documentation Description *
Document Description Doc Number Description
FS20 System Description A6V10315009 Overview of the FS20 System structures and function
FS20 Planning A6V10315013 Provide information on project planning for the system and
individual devices
FS20 Mounting, Installation,
Product Data
A6V10315015 Provide HW reference document. This contains the wiring
connection, electrical rating, module setting and compatible
accessories for each individual module. Provides detailed
description on how each module is installed in the enclosure
and how internal and external wiring are routed. *
FS20 Commissioning,
Maintenance, Troubleshooting
A6V10315021 Provides instructions for commissioning, maintenance and
troubleshooting of the whole fire detection system.
FS20 Configuration A6V10315023 Provides instructions how to use the Desigo Works
Configuration Tool to configure ad program the system.
FC20xx Operation Manual A6V10315017 Provides the detailed operating instruction of the system after
it has been configured.
FC2025 / FC2050 Installation
Instructions
A6V10337045 Provides a summary and overview of the FS20 Fire Alarm
Control Panel.
(*) – Note that only the modules / devices / appliances listed in this manual can be used for Marine Application
