FS20 Marine Fire Detection Control Panel
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
3 Description of FS20 Fire Alarm Control Panel
3.1 Introduction
The FS20 system is a life safety system that is modular, networkable fire detection systems that can consist of
FC2025/FC922 and/or FC2050/FC924 Fire Alarm Control Panel (FACP). It comprises of all the components
required for the detection, evaluation and annunciation of life safety event such as fire and smoke condition. By
using optional modules, copper wiring cables can be used to network the panels together.
The FC2025 / FC922 FACP is capable of supporting up to 252 devices and FC2050/FC924 FACP is capable of
supporting up to 504 devices. Both panels have a PMI with optional LED module, 2 Class B or 1 Class A NAC, 4
control relays, battery charger capability and auxiliary power connection. Both panels support a DACT capability,
connection to Remote Annunciator and Releasing Application as optional features. All panels use 170W power
supply and EMI filter with terminal block that comes with the FH2071-UM enclosure.
Many parts used in the FC922 / FC924 / FC2025 / FC2050 Marine FACPs have passed Salt-Mist-Spray
requirements for
Exceptional Degree of Protection
, per USCG guidelines. For a list of devices that are approved for
Salt-Mist-Spray, see section 28,
Equipment List for Marine Applications.
For Marine Application, FH2071-UM enclosure was designed specifically for marine application with built-in shock
mounting is used to be able to absorb vibration and comes with seismic battery bracket.
3.2 Minimum panel requirement for Marine Application
The HW list below is minimum required for FS20 panel for Marine Application:
- FH20710UM Marine Enclosure: this comes with pre-installed shock mounting plate, EMI filter,
battery bracket, Terminal block and outer door with built-in water-tight plexiglass.
- FP2011-U1 170W Power Supply
- FHD2004-U1 Inner Door (for operating unit)
- FCM2018 –U2/U3 (or FC2019-U2/U3) Operating unit
- FCI2016-U1 (or FCI2017-U1) Periboard
- BP-62 16Ah Battery Set for Marine Application
