Siemens FC924 User Manual

FS20 Marine Fire Detection Control Panel
129
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
28 Equipment Lists for Marine Application
Below are list of equipment for the FS20 panels for marine application.
28.1 Desigo Channel
28.1.1 System
Model Number Part Number Description Data Sheet #
FC2025 S54400-C4-A1 Fire Alarm Panel 252 Point (Desigo) 6815
FC2050 S54400-C5-A1 Fire Alarm Panel 504 Point (Desigo) 6815
28.1.2 System Modules
Model Number Part Number Description
FT2014-R2 ^ S54400-B75-A1 Remote Display (Red)
FT2015-R2 ^ S54400-B15-A1 Remote Display Terminal (with control)
FT2014-U2 ^ S54400-F67-A1 System Display (View, Black)
FT2015-U2 ^ S54400-F68-A1 Remote Display Terminal (with control)
FCM2018-U2 ^ ☼ S54400-C40-A1 Operating Interface Unit
FCM2019-U2 ^ ☼ S54400-C41-A1 Operating Interface Unit w/LEDs
FCM2035-U2 ^ ◘ S54400-C139-A1 Operating Interface Unit w/ LEDs (ULC Listed)
28.1.3 Initiating Devices
Model Number Part Number Description
FDO421 ^ S54320-F4-A1 Optical Detector
FDOOT441 S54320-F7-A1 Dual Optical + Heat Detector
FDOOTC441 S54320-F8-A1 Dual Optical + Heat + CO Detector
FDOT421 ^ S54320-F6-A1 Optical + Heat Detector
FDT421 ^ S54320-F5-A1 Heat Detector
^ denotes orderable, USCG Approved item meet USCG’s requirements for use in applications requiring an Exceptional
Degree of Protection.
◘
Application Note:
For installations requiring ULC approval, you must use Operating Unit, Model FCM2035-U2 (P/N
S54400-C139-A1)
☼Application Note:
For installations requiring U.S. Coast Guard approval, you must use Operating Unit, Models FCM2018-
U2 (P/N S54400-C40-A1) and FCM2019-U2 (S54400-C41-A1)
