Siemens FC924 User Manual

FS20 Marine Fire Detection Control Panel
136
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
Appendix A: Inscription Strips Instructions
Installing Fonts
The 'Siemens Sans' font is required in order to display the inscription correctly on the system-
operating unit.
A zip file with various 'Siemens Sans' fonts is included in this help set. A link to the zip file is
provided in the HTML web of the FS20 documentation under Mounting/Installation in the
STEP Portal.
https://workspace.sbt.siemens.com/content/00001123/default.aspx
Key word:
A6V10361327
1. Download and unzip the zip file locally on your PC.
2. Install all fonts via System control
or
3. Open the 'Fonts' directory on your PC and use 'drag and drop' to move all 'Siemens Sans'
fonts into this directory.
 'Siemens Sans' is installed on your PC.
Entering/Changing Text
The figures showing inscription strips in this document are in EMF file format and can be
changed within the document. The correct font is 'Siemens Sans'.
 Microsoft Office Word 2003 or higher is installed on your PC.
 'Siemens Sans' is installed on your PC.
1. Left-click to select the figure.
2. Right-click on the figure.
 The context menu is opened.
3. Select 'Edit Picture'.
 You can modify the text.
