17.5 Adjusting Elements for NAC 2
17.5.1 X602 Jumper
Degraded Mode Enable/Disable for NAC 2 class A or NAC 2-1 class B
Switching on the degraded mode function of the NAC circuit 2 class A or circuit 2-1
class B
X602
Jumper position
Function
Definition
1
2
3
3 - 2 Disable degraded
mode for NAC 2 class
A or NAC 2-1 class B.
Circuit will not activate the notification appliances if degraded
mode is activated and an alarm is present.
1 - 2 Enable degraded
mode for NAC 2 class
A or NAC 2-1 class B.
Circuit will activate the notification appliances if degraded mode is
activated and an alarm is present.
17.5.2 X603 Jumper Degraded Mode Enable/Disable for NAC 2-2 class B
Switching on the degraded mode function of the circuit 2-2 class B
X603
Jumper position
Function
Definition
1
2
3
3 - 2 Disable degraded
mode on NAC 2-2
class B.
Circuit will not activate the notification appliances if degraded
mode is activated and an alarm is present.
1 - 2 Enable degraded
mode on NAC 2-2
class B.
Circuit will activate the notification appliances if degraded mode is
activated and an alarm is present.
17.5.3 X604, X605 and X606 NAC 2 class A/B selection jumper
Class A/B setting of the additional NAC circuit
X604
X605
X606
Jumper position
Function
Definition
1
2
3
3 - 2 Class A Configures periphery board NAC 2 for class A circuit
1 - 2 Class B Configures periphery board NAC 2-1 and NAC 2-2 for class B
circuit
The setting for class A/B must also be configured with the Engineering tool set. If the
configuration does not match the onboard jumper settings, an error will post on the
Operating Unit.
