Siemens FC924 User Manual

FS20 Marine Fire Detection Control Panel
68
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
12.7 Indicators
Standard LED indicators
LED
Color
Condition
Definition
H1301 Yellow OFF Default
ON Startup problems network core A (clock)
1 flash every 2 seconds Failsafe active (no communication to the O
perating
Unit)
2 fast flashes (every 2 seconds) Failsafe active + local alarm
1 fast flash (every 1 second) Failsafe active + signaling (local alarm)
Flash (every 1 second) and 2 fast flashes
(every 2 seconds)
Failsafe active + local alarm + signaling
H1701 Yellow OFF Default
ON Startup problems network core B (clock)
1 flash every 2 seconds
Failsafe active (no communication to the Operating
Unit)
2 fast flashes (every 2 seconds) Failsafe active + local alarm
1 fast flash (every 1 second) Failsafe active + signaling (local alarm)
Flash (every 1 second) and 2 fast flashes
(every 2 seconds)
Failsafe active + local alarm + signaling
12.8 Reset Buttons
12.8.1 S100 RESET Periphery Board
Button
Function
Position
Definition
S100 Reset main microprocessor on
periphery board
Not pressed Normal
Pressed Resets only the main microprocessor on the periphery board
12.8.2 S1201 RESET Core ‘A’ Detector Circuit
Button
Function
Position
Definition
S1201 Reset main microprocessor for
core A detector circuit
Not pressed Normal
Pressed Resets only microprocessor on core A detector circuit
12.8.3 S1601 RESET Core ‘B’ Detector Circuit
Button
Function
Position
Definition
S1601 Reset main microprocessor for
core B detector circuit
Not pressed Normal
Pressed Resets only microprocessor on core B detector circuit
