FS20 Marine Fire Detection Control Panel

Siemens Industry, Inc. A6V10519176_enUS_b

Building Technologies Division

16.2 Installation

The RS-485 class ‘A’ serial module (iso.) FCA2016-U1 must be installed in the specified

slots in the operating unit. Installation is the same for each slot.

Slots for serial modules in the operating unit

1 Serial module in slot X19

2 Serial module in slot X14
