Siemens FC924 User Manual

FS20 Marine Fire Detection Panel Control Panel
33
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
6.5 Inserting the Inscription Strips
1
2
3
5
4
Inserting the inscription strips into the operating unit
1 Inscription LEDs
2 Inscription for the standard keys in the center
3 Inscription for standard keys on the right
4 Inscription for LED module (depending on whether operating unit is present or not)
5 Inscription for panel and alarm
The template for the inscription strips is located in the Appendix on page 136.
