Siemens FC924 User Manual

FS20 Marine Fire Detection Control Panel
120
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
25.5 Commissioning with Manual Configuration
NOTICE
Commissioning as standalone ‘Panel’
‘Panels’ commissioned as standalone Panel cannot be combined to form a network ‘Site’ late
on.
•
Initialize network ‘Panels’ using a network address at the beginning of the process.
Prerequisites:
• The detector circuits and Network devices are installed.
• The detector circuits and Network devices are configured and tested with the ‘Device
programming unit’ DPU.
• The ‘Panel’ is installed.
• The batteries are installed but not connected.
• The cables for the detector circuits and mains supply have been fed into the ‘Panel’ but are
not yet connected.
• The configuration tool is installed on the PC.
• The current firmware and BDV are available on the PC.
Commissioning for Standalone ‘Panel’
1. Manually create and configure a ‘Site’ in the configuration tool.
2. Prepare the ‘Panel’ for commissioning – without BDV installation.
3. Connect the PC to the ‘Panel’.
4. Load the configuration from the PC to the Panel.
5. Test the function of the ‘Site’.
6. Rectify errors if necessary and load the correct configuration from the PC to the ‘Panel’.
7. Disconnect the PC from the ‘Panel’.
8. Perform the completion work.
Commissioning for Network ‘Panel
1. Manually create and configure a ‘Site’ in the configuration tool.
2. Individually prepare each ‘Panel’ for commissioning – without BDV installation.
3. Individually connect the PC to each ‘Panel’
4. Individually initialize each ‘Panel’
5. Test the function of the ‘Site’.
6. Rectify errors if necessary and load the corrected configuration form the PC to the ‘Panel’.
7. Disconnect the PC from the ‘Panel’.
8. Perform the completion work.
