FS20 Marine Fire Detection Control Panel
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
28.3.3 Peripherals and Specialized Devices
Model Number Part Number Description
DB-11 ^ 500-094151 Detector Base Assy.
DB-11E ^ 500-094151E Detector Base Assy.
DB11-Seal ^ 500-695622 Seal Package (24 pc)
DB2-HR ^ S54370-F12-A1 Relay Base
DB-Seal ^ 500-692211 Detector Gasket 36 Box
FDBZ492
1
^ S54319-B22-A1 Duct Housing
FDBZ492-HR
1
^ S54319-B23-A1 Duct Housing with Addressable Relay
FDBZ492-R
1
^ S54319-B24-A1 Duct Housing with Conventional Relay
FDBZ492-RP
1
^ S54319-B25-A1 Powered Duct Housing with Conventional Relay
FDBZ492-RTL ^ S54319-S27-A1 Remote Alarm Indicator
FDBZ-WT ^ S54319-B26-A1 Weatherproof Housing Duct
FDCIO422 ^ S54322-F4-A1 4 Input 4 Output Module
FDCIO-EOL ^ S54312-F7-A1 EOL for FDCIO422
HZM ^ 500-034850 Conventional Zone Module
HMS-M ^ 500-033450 Manual Pull Station (Metal)
HTRI-D* ^ 500-033360 Intel Interface (Dual)
HTRI-M ^ 500-034000 Mini Interface Module
HTRI-R* ^ 500-033300 Intel Interface W relay
HTRI-S* ^ 500-033370 Intel Interface Module
TB-EOL ^ S54322-F4-A2 Terminal Block for FDCIO-EOL
* For Marine installation, the plastic face for the HTRI Series of detectors must be replaced with a metal plate using the
ground wire. The P/N for the metal plate is: S54319-F22-A1
1
When ordering the Duct Housing, Model FDBZ-WP is the required duct housing for Marine
installation.
^ denotes orderable, USCG Approved item meet USCG’s requirements for use in applications requiring an Exceptional
Degree of Protection.
