FS20 Marine Fire Detection Control Panel
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
Commissioning for Standalone ‘Panel’ Variant 2
With commissioning variant, first manually configure a ‘Site’ as far as the ‘Circuit’ level in the
configuration tool. Then auto-configure the detectors circuits and adapt the configuration manually the
configuration tool.
1. Create a ‘Site’ in the configuration tool and configure it manually as far as the ‘Circuit’ level.
2. Prepare the ‘Panel’ for commissioning – without BDV installation.
3. Connect the PC to the ‘Panel’.
4. Load the configuration from the PC to the ‘Panel’.
5. Auto-configure the detector circuits.
6. Load the configuration from the ‘Panel’ to the PC.
7. Adapt the configuration in the configuration tool.
8. Load the configuration from the PC to the ‘Panel’.
9. Test the function of the ‘Site’.
10. Rectify errors if necessary and load the corrected configuration from the PC to the ‘Panel’.
11. Disconnect the PC from the ‘Panel’.
12. Perform the completion work.
Commissioning for Network ‘Panels’
1. Create a ‘Site’ and the ‘Panels’ in the configuration tool.
2. Individually prepare each ‘Panel’ for commissioning – without BDV installation.
3. Individually connect the PC to each ‘Panel’.
4. Individually initialize each ‘Panel’.
5. Perform the auto-configuration on each ‘Panel’.
• ‘Auto-configure Panel’ or
• Individually auto-configure detector circuits.
6. Load the configuration form the ‘Panel’ to the PC.
7. Adapt the configuration in the configuration tool.
8. Load the configuration from the PC to the ‘Panel’.
9. Test the function of the ‘Site’.
10. Rectify errors if necessary and load the corrected configuration from the PC to the ‘Panel’.
11. Disconnect the PC from the ‘Panel’.
12. Perform the completion work.
