FS20 Marine Fire Detection Control Panel
70
Siemens Industry, Inc. A6V10519176_enUS_b
Building Technologies Division
Detector Circuits
Terminal strips X1401 circuit card 1, circuit 1
X1402 circuit card 1, circuit 2
X1801 circuit card 2, circuit 3
X1802 circuit card 2, circuit 4
Output voltage 24VDC, filtered
Number of integrated circuit cards 2
Output current per integrated
circuit card
Max. 500 mA
Addressable devices per
integrated circuit card
Max. 252
Connectable circuits per integ
rated
circuit card
2 style 6 or 4 style 4 (mixed variants are possible)
Protocol Network
Circuit resistance Max. 180 Ω
Capacity 500 nF per circuit
Cable types All (twisted recommended)
For specifications detail, refer to the following
documents:
A6V10315013 for Desigo
Connectable devices See List of compatibility
Monitored for Ground fault
Short circuit
Open circuit
Circuit capacitance
Design Short-circuit-proof
Voltage surge protection
Open circuit
Power limited
Relay Contacts
Plug strip X1201
Design Relay output
Break or make contact
Nonpower limited
Alarm and trouble active in degraded mode
operation
Switching voltage 30VDC or AC 120VAC ohmic
Switching current 5 A, Max.
Connection Terminals
Inputs, outputs and detector
circuits:
Design Plug-in screw terminals
Admissible cable cross-
section
Once 12...18 AWG or twice 16...18 AWG
18 gauge twisted pair, shielded cable.
