● Comment
The comment is read from HW Config.
● Last update
The timestamp of the last update of the identification data is displayed.
● Status
The following table shows the symbolic identification of the origin of the data:
Icon identification Meaning
No icon No information on the data source
Device data
The data source is the device.
Project data
The data source is the project.
No data were read from the device.
Operator control
Icon Explanation Permission
You update the display of identification data by
clicking the icon.
"Process controlling" for the diagnos‐
tics area
Additional information
You can find information on displaying redundant components in the faceplate in the section
"Display of faceplate for redundant components (Page 182)".
6.11.3.2 "Messages" view
Available
This view is displayed for all components.
Note
This view is available for the maintenance station in the MS Standard and SIMATIC PDM MS
versions.
Overview
This view contains all messages that are present for a component.
The following messages are displayed:
● Diagnostic/error messages
● Operating messages after selection of the long-term archive list in the toolbar
Operator control and monitoring
6.11 Faceplate
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 145
