With complete export, the data from all the components with diagnostics functionality is

exported to the export file "@XML_Export.sml".

The complete export file is stored in the default target directory on the MS in the "AssetExport"

folder of the OS project directory.

The complete export file is stored on both partners in a redundant system.

The complete export file can also be stored in a configured target directory (e.g., for reuse of

the data in external systems).

You can find information on this in the section "Storage location for the files of the (filtered)

total export (Page 66)".

In the process control, the system allows you to display the data of the last complete export

in filtered form and to export this data.

Additional information

You can find additional information about displaying and exporting the data in process control

in the section "Functions in the overview screen (Page 97)".

5.16 Overview of individual export

Overview

Note

You use this function if you are using the MS Standard or SIMATIC PDM MS version of the

maintenance station.

Data of a diagnostics-capable component (such as field devices, PCs, AS components,

network components) can be exported.

During an individual export, the data of a diagnostics-capable component is written to an export

file.

The file name is automatically generated by the system.

The individual export file is stored in the default target directory on the MS in the "AssetExport

\Out" folder in the OS project directory.

The individual export file is stored in the standard target directory on the connected OS server

(current preferred server) in a redundant system.

The individual export file can also be stored in a configured target directory (e.g. for reuse of

the data in external systems).

You can find information on this in the section "Configuring maintenance targets for individual
