Additional information
You can find information on the redundancy state in the section "Maintenance status of
redundant components (Page 126)".
6.12 Origin of the identification data
6.12.1 Identification data for IPCs
Where does the identification data for IPCs come from?
In the case of the faceplate for IPC objects, the identification data is read from the device via
an SNMP connection.
The device must be configured in the SNMP OPC Server of the maintenance station for this.
These data are prepared for display on the maintenance station with the "Export tags for
WinCC" function.
The following table shows the assignment of the identification data displayed on the MS to the
origin.
Identification data Origin
SNMP Profile V1.5 for IPC PC with support of the SNMP
Profile MIB-II
TAG / HID SNMP tag ".sysName" Not available
LID Object properties of the PC station "Name"
Address HW Config/OPC server "IP address" /
SNMP tag "&ipAddress()"
IP address terminal bus
CCAgent
Description Not available
Message
Device type SNMP tag ".ProductName" Not available
Manufacturer SNMP tag ".Manufacturer" Not available
Article number
1)
SNMP tag ".StationMLFB" Not available
Serial number SNMP tag ".StationSerialNumber" Not available
Installation date Not available
HW revision SNMP tag ".HwVersion" Not available
SW revision SNMP tag ".SwVersion" Not available
Last update Time stamp of the updating of the identification data
Comment Object properties of the PC station "Comment"
1)
Article number = also order number or MLFB
Operator control and monitoring
6.12 Origin of the identification data
Maintenance Station
Function Manual, 03/2016, A5E36187641-AA 183
